Horizontal Spindle Rotary Surface Grinding Machine

Specification
CHS-500A CHS-600A unit
Rotary table diameter 500 600 mm
Rotary table speed 0 ~ 150 0 ~ 150 RPM
Grinding wheel size Ø355x50xØ127
( OD x W x ID )		 Ø355x50xØ127
( OD x W x ID )		 mm
Wheel spindle speed 1750
(7.5HP - 60HZ)		 1750
(10HP - 60HZ)		 RPM
Distance from center of wheel spindle to chuck top 350 350 mm
Tilt angle of table ±3° ±3° angle
Machine size
( L x W x H )		 2100x1500x2100 2100x1500x2100 mm
Weight 3000 3200 kg
